Brand Name : GS
Model Number : GS-RAD2203
Place of Origin : China
MOQ : 1 PCS
Price : USD+negotiable+pcs
Payment Terms : T/T
Supply Ability : 1+pcs+per days
Delivery Time : 1-7 days
Packaging Details : 950*60*180mm
Model : GS-RAD2203
External dimensions (length * width * height) : 740*47*144(110)mm(The height from the bottom to the feeding port: 110cm Height at the highest point (from the bottom to the handle) : 144mm)
Weight : 6KG
Working voltage : DC 24V
Gas source requirements : no
Maximum current : 3A
Feeding speed : 0.6-2s/Pcs
Drive mode : Pure electric
Operation panel : 0.96-inch TFT color screen 80*160 pixels
Error in the length of the material cutting feet : ±0.2mm
Applicable to the hole spacing of the tape : 12.7mm/15mm(Parts need to be replaced)
Function of cutting waste tape : Optional(DK-RAD2203: With a cutter DK-RAD2101: No cutter)
Bending function : Optional separately(The bending function can be customized according to the material)
The number of times the cutter is used : ≥1 million
48mm Radial Feeder(GS-RAD2203)-[with cutter]
The Radial feeder is an electronic component supply device that maintains a certain interval and sends out the electronic components of the Radial tape packaging one by one at a specified time, cuts the lead wires, and supplies them to the insertion machine.
If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize feeders.
![]() |
48mm Radial Feeder GS-RAD2203 with cutter Working Voltage DC 24V For 12.7mm/15mm Tape Hole Spacing Images |
