Surface Mount IC Tube Mounting Tubular Feeder GS-SAQ2206 Single Channel DC 24V

Brand Name : GS

Model Number : GS-SAQ2206

Place of Origin : China

MOQ : 1 PCS

Price : USD+negotiable+pcs

Payment Terms : T/T

Supply Ability : 1+pcs+per days

Delivery Time : 1-7 days

Packaging Details : 1350*60*450

Model : GS-SAQ2206

Overall dimensions (length * width * height) : 1160*46*345

Working voltage : DC 24V

Gas source requirements : 0.4-0.7Mpa

Maximum current : 1A

Feeding speed : 0.6s/Pcs

Operation panel : 0.96-inch TFT color screen, 80*160 pixels

Pipe replacement time : ＜5S

Channel : Single channel

Adapt to the length of the material pipe : 490-535mm

Adapt to the height of the material pipe : 3.5-5.5mm

Adapt to the width of the material pipe : 8/11/15mm

Contact Now

Surface Mount IC Tube Mounting (GS-SAQ2206)

The tubular feeder is a tubular electronic component supply device that supplies tube-mounted electronic components to the insertion machine one by one at a specified time through vibration and air blowing.

Surface Mount IC Tube Mounting Tubular Feeder GS-SAQ2206 Single Channel DC 24V

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.

Product Tags:

Single Channel Tubular Feeder

DC 24V Tubular Feeder

Surface Mount IC Tube Mounting Tubular Feeder GS-SAQ2206 Single Channel DC 24V Images
